Industrial UAVs have been widely used in agriculture, construction, energy, logistics, environmental monitoring, security rescue, surveying and other fields. Our advanced SGT technology effectively improves efficiency and power density.

Solutions

Our Products

Select	AKS Part Number	Status	Spice model	Package	Cfg.	VDS(V)	Vgs(V)	ID(A)	Vth_Typ(V)	RDSon_Typ @10V(mΩ)	RDSon_Max @10V(mΩ)	RDSon_Typ @4.5V(mΩ)	RDSon_Max @4.5V(mΩ)	CISS_Typ (pF)	COSS_Typ (pF)	CRSS_Typ (pF)	QG_Typ (nC)
Select
	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter
	AK1G4N007GAL-T Datasheets Marking POD Tape&reel	MP	-	PDFN5*6	N	40	±20	345	1.8	0.59	0.7	0.92	1.45	6760	2700	67	92
	AKG3N015GL Datasheets Marking POD 1 POD 2 POD 3 Tape&reel 1 Tape&reel 2 Tape&reel 3	MP	-	PDFN5*6	N	30	20	165	1.7	1.3	1.5	2.2	2.8	2874	1151	76	46.5
	AKG3N015QL	MP	-	PDFN3.3*3.3	N	30	20	150	1.7	1.3	1.5	2.2	2.8	2874	1151	76	46.5
	AKG30N011G	MP	-	PDFN5*6	N	30	20	200	1.7	0.9	1.1	1.5	1.8	3700	1500	90	60.4
	AKG40N013G Datasheets Marking POD 1 POD 2 Tape&reel 1 Tape&reel 2	MP	-	PDFN5*6	N	40	20	176	1.5	1.1	1.3	1.6	2	3900	1460	32.9	63.1
	AKG40N011G AKG40N011G	MP	-	PDFN5*6	N	40	20	200	1.7	0.9	1.1	1.3	1.5	4988	1738	71	77
	AKG4N008GM AKG4N008GM	MP	-	PDFN5*6	N	40	20	320	2.8	0.6	0.8	-	-	8980	3560	36	110
	AK1G4N007GAL AK1G4N007GAL	MP	-	PDFN5*6	N	40	20	345	1.8	0.6	0.7	1.1	1.4	6900	2800	48	98
	AKG3N022GL AKG3N022GL	MP	-	PDFN5*6	N	30	20	125	1.7	1.9	2.2	2.8	3.5	2135	790	87	38
	AKG3N013GL AKG3N013GL	MP	-	PDFN5*6	N	30	20	190	1.7	1	1.3	1.5	2	4520	1390	212	83
	AKG3N015GL-T AKG3N015GL-T	MP	-	PDFN5*6	N	30	20	165	1.8	1.3	1.5	2.2	2.8	2655	1205	60	40
	AK1G4N009GAL AK1G4N009GAL	MP	-	PDFN5*6	N	40	-	260	2.0	0.6	0.9	1.2	1.6	5715	2480	38	78
	AKG40N013G-T Datasheets Marking POD 1 POD 2 POD 3 Tape&reel 1 Tape&reel 2 Tape&reel 3	MP	-	PDFN5*6	N	40	±20	183	1.7	1.05	1.3	1.6	2	3970	1300	55	60
