As the core component of motor drive, power devices provide sufficient guarantee for the stable operation of small household appliances. Our SGT technology provides cost-effective products.
Solutions
Our Products
| Select | AKS Part Number | Status | Spice model | Package | Cfg. | VDS(V) | Vgs(V) | ID(A) | Vth_Typ(V) | RDSon_Typ @10V(mΩ) |
RDSon_Max @10V(mΩ) |
RDSon_Typ @4.5V(mΩ) |
RDSon_Max @4.5V(mΩ) |
CISS_Typ (pF) |
COSS_Typ (pF) |
CRSS_Typ (pF) |
QG_Typ (nC) |
| MP | - | PDFN5*6 | N | 30 | 20 | 430 | 1.6 | 0.4 | 0.5 | 0.6 | 0.8 | 13210 | 4055 | 950 | 240 | ||
| MP | - | PDFN5*6 | N | 30 | 20 | 165 | 1.7 | 1.3 | 1.5 | 2.2 | 2.8 | 2874 | 1151 | 76 | 46.5 | ||
| MP | - | PDFN3.3*3.3 | N | 30 | 20 | 150 | 1.7 | 1.3 | 1.5 | 2.2 | 2.8 | 2874 | 1151 | 76 | 46.5 | ||
| MP | - | PDFN5*6 | N | 30 | 20 | 200 | 1.7 | 0.9 | 1.1 | 1.5 | 1.8 | 3700 | 1500 | 90 | 60.4 | ||
| MP | - | PDFN5*6 | N | 30 | 20 | 125 | 1.7 | 1.9 | 2.2 | 2.8 | 3.5 | 2135 | 790 | 87 | 38 | ||
| MP | - | PDFN5*6 | N | 30 | 20 | 190 | 1.7 | 1 | 1.3 | 1.5 | 2 | 4520 | 1390 | 212 | 83 | ||
| MP | - | PDFN3.3*3.3 | N | 30 | 20 | 150 | 1.8 | 1.3 | 1.5 | 2.2 | 2.8 | 2655 | 1205 | 60 | 39 | ||
| MP | - | PDFN5*6 | N | 30 | 20 | 165 | 1.8 | 1.3 | 1.5 | 2.2 | 2.8 | 2655 | 1205 | 60 | 40 | ||
| MP | - | PDFN5*6 | N | 30 | 20 | 288 | 1.7 | 0.6 | 0.7 | 0.8 | 1.0 | 8334 | 2849 | 648 | 140 |
