We provide a range of SGT MOSFETs that match multiple application scenarios.
Solutions
Our Products
| Select | AKS Part Number | Status | Spice model | Package | Cfg. | VDS(V) | Vgs(V) | ID(A) | Vth_Typ(V) | RDSon_Typ @10V(mΩ) |
RDSon_Max @10V(mΩ) |
RDSon_Typ @4.5V(mΩ) |
RDSon_Max @4.5V(mΩ) |
CISS_Typ (pF) |
COSS_Typ (pF) |
CRSS_Typ (pF) |
QG_Typ (nC) |
| MP | - | PDFN5*6 | N | 30 | 20 | 125 | 1.7 | 1.9 | 2.2 | 2.8 | 3.5 | 2135 | 790 | 87 | 38 | ||
| MP | - | PDFN5*6 | N | 30 | 20 | 165 | 1.8 | 1.3 | 1.5 | 2.2 | 2.8 | 2655 | 1205 | 60 | 40 | ||
| MP | - | PDFN5*6 | N | 40 | 20 | 183 | 1.7 | 1.1 | 1.3 | 1.6 | 2 | 55 | 1300 | 55 | 60 | ||
| MP | - | PDFN5*6 | N | 40 | 20 | 214 | 1.6 | 1.3 | 1.6 | 2 | 2.5 | 2955 | 1100 | 28 | 46 |
