In response to the increasingly high system requirements, we offer products of different specifications and packaging types, covering HVAC, PTC, water pumps, fans, etc., with product types covering low-voltage SGT MOS, high-voltage IGBT, SiC MOSFET product types, providing a complete set of TMS power solutions.
Solutions
Our Products
| Select | AKS Part Number | Status | Spice model | Package | Cfg. | VDS(V) | Vgs(V) | ID(A) | Vth_Typ(V) | RDSon_Typ @10V(mΩ) |
RDSon_Max @10V(mΩ) |
RDSon_Typ @4.5V(mΩ) |
RDSon_Max @4.5V(mΩ) |
CISS_Typ (pF) |
COSS_Typ (pF) |
CRSS_Typ (pF) |
QG_Typ (nC) |
| MP | - | PDFN5*6 | N | 40 | 20 | 130 | 3.0 | 2.1 | 2.5 | - | - | 3055 | 862 | 29 | 36 | ||
| MP | - | PDFN5*6 | N | 40 | 20 | 235 | 3.0 | 0.9 | 1.2 | - | - | 5810 | 1640 | 15 | 72 | ||
| MP | - | PDFN5*6 | N | 40 | 20 | 90 | 3.0 | 2.5 | 3.5 | - | - | 1860 | 560 | 15 | 22.5 | ||
| MP | - | PDFN5*6 | N | 40 | 20 | 40 | 3.0 | 4.8 | 5.8 | - | - | 1220 | 360 | 12 | 15.5 | ||
| MP | - | PDFN5*6 | N | 40 | 20 | 250 | 3.0 | 0.8 | 1.1 | - | - | 5810 | 1640 | 15 | 72 |
Filter
| Select | AKS Part Number | Package | Status | Spice model | VDS(V) | Vgs(V) | ID(A) | Vth_Typ(V) | RDSon_Typ @18V(mΩ) |
RDSon_Max @18V(mΩ) |
RDSon_Typ @15V(mΩ) |
RDSon_Max @15V(mΩ) |
CISS_Typ (pF) |
COSS_Typ (pF) |
CRSS_Typ (pF) |
QG_Typ (nC) |
| TO-247-4L | MP | - | 1200 | -6 | 35 | 3.2 | 80 | 95 | - | - | 1295 | 65 | 8 | 68.6 |
